1000pcs/min N Fold Hand Towel Machine With Vacuum Pump
|
商品の詳細:
お支払配送条件:
|
詳細製品概要
| 浮彫りになること: | 鋼鉄への鋼鉄 | 速度: | 800-1000pcs/min/lane |
|---|---|---|---|
| 電圧: | 380v、50Hz | 真空ポンプ: | ルーツ真空ポンプ |
| backstand: | 1-2sets | 保証: | 1年 |
| 売り上げ後のサービスは提供した: | 利用できるエンジニア機械類を海外に整備するため | 力（w）: | 15KW |
| ハイライト: | 1000pcs/min Hand Towel Machine,15KW Hand Towel Machine,840mm Tissue Paper Production Line |
||
High Quality and Service Automatic N Folded Hand Towel Folder Rewinding Machine
N fold Hand Towel Machine with Vacuum Pump stable speed with steel to steel embossing unit
ZH-NF210/215/225 N Folded Hand Towel Folding Machine
Features:
- High speed:800-1000 sheet/min
- Multifunction:hand towel and kitchen towel can be made
- Control system:SIEMENS PLC
Parameters:
| MODEL | 3T | 4T | 5T | 6T |
| Max. Width of jumbo roll | 630mm | 840mm | 1050mm | 1260mm |
| Slitting knife | 3sets in back and front | 4sets in back and front | 5sets in back and front | 6sets in back and front |
| Vacuum pump | 11Kw | 11Kw | 15kw | 18.5kw |
| Main driving motor powe | 4kw | 4kw | 5.5kw | 5.5kw |
| Machine size | 6×1.8×1.9m | 6×2×1.9m | 6×2.3×1.9m | 6×2.5×1.9m |
| Machine weight | 3500kg | 4500kg | 5500kg | 6500kg |
| Machine speed | 500-1000 sheet/min/lane | |||
| Max.diameter of jumbo roll | Ф1200mm(other sizes can be ordered) | |||
| Inner diameter of jumbo roll | Ф76.2mm(other sizes can be ordered) | |||
| Bankstand | 2-6 jumbo rolls (should be ordered) | |||
| Embossing unit | Steel to rubber,steel to paper,steel to steel(should be ordered) | |||
| Lamination unit | Should be option | |||
| Edge embossing unit | Air bag type,bearing pattern(should be ordered) | |||
| Air pressure | 0.8Mpa(user supplied) | |||
